- Power handling RMS / max. P 300 / 600 Watts
- Impedance Z 1 x 2 Ω
- DC resistance Re 1 x 2.0 Ω
- Resonance frequency Fs 32 Hz
- Mechanical Q factor Qms 5.09
- Electrical Q factor Qes 0.45
- Total Q factor Qts 0.41
- Compliance Cms 159 μm/N
- Equivalent air volume Vas 25 L
- Force factor B*I 12.1 Tm
- Sensitivity SPL
- 93.0 dB @ 2.83V / 1m
- 87.0 dB @ 1W / 1m
- Cone area Sd 333 cm²
- Moving mass Mms 126 g
- Cone material Hand-scooped paper cone
- Mechanical resistance Rms 6.25 kg/s
- Voice coil diameter ø 50.8 mm
- Voice coil winding height 24 mm
- Max. linear excursion Xmax +/- 8.0 mm
- Outer diameter ø 262 mm / 10.31"
- Installation diameter ø 232 mm / 9.13"
- Installation depth 126 mm / 4.96"
- Recommended enclosure volumes
- Sealed box
- Net volume 15 L
- Lower limiting frequency (-3dB) 50 Hz
- Recommended DSP settings “Self-Define” Highpass: 38 Hz / Q = 1.4;
- EQ Filter: 95 Hz / Q = 1.0 / -3 dB
- Vented box
- Net volume 21 L
- Port diameter ø 70 mm / 2.76"
- Port area 38 cm²
- Port length 32 cm / 12.6"
- Port tuning frequency Fb 36 Hz
- Lower limiting frequency (-3dB) 36 Hz
- Recommended DSP settings “Self-Define” Highpass: 35 Hz / Q = 1.0;
- EQ Filter: 100 Hz / Q = 0.7 / -2 dB
